LOCATION

ZOOMLITE

The ZOOMLITE is a fluorescent light for location with manual dimming and focus control. It is intended for news crews and videographers needing low amperage draw with high output and superior light quality. Shadows are soft and lighting is even. The focus control sets the angle of coverage.
At full power, 45 W, equivalent to 300 W Tungsten.
Very low amperage draw.
Up to 1300 Lux (120 FC) at 2m (6.8 ft).
25% to full continuous dimming with no change in color temperature.
Soft shadows and very even lighting.
Change bulbs to change color temperature, with no loss of output.
Long lamp life and no heat.
  ZOOMLITE 45
POWER
 45W
CANDELAS
5,200
WORKING DISTANCE
0.5-3 m / 1-10 ft
AMPERAGE
0.4 A (120V), 0.2 A (230V)
OUTPUT
Spot
Flood
at 2m (6.6ft)
1300 Lux/120 FC
750 Lux/75 FC
ANGLE
15° to 45°, totally even
COLOR
3200°K or 4200°K
VOLTAGE
120 V or 230V
DIMMING
Manual, full to 3%, continuous
WEIGHT
1.9 Kg/4.2 lbs
ACCESSORIES
grid-spots, reflectors





High efficiency fluorescence is now available on battery (11-17 Vdc) for high output, high quality location shooting. Use the CAMFLUX either on camera or hand-held instead of A/C lighting kits. Multiply battery life by 3 or avoid A/C connections altogether.

CAMFLUX
3 times longer lasting batteries for equivalent light output.
At full power, equivalent to 100W tungsten. 375 LUX (35 FC) at 2m (6.8 ft)
25% to full continuous dimming with no change in color temperature, and with reduction of power consumption.
Soft shadows and very even lighting.
Change bulbs to change color temperature, with no loss of output.
Long lamp life and no heat.
  CAMFLUX 30
POWER
 30W
CANDELAS
1,500
WORKING DISTANCE
0.5-2.5 m / 1-8 ft
AMPERAGE
3 A (full) to 1 A (1/4 power) no surge current
OUTPUT
370 Lux/34 FC (2m / 6.6 ft)
ANGLE
40°, totally even
COLOR
3200°K or 4200°K
VOLTAGE
10.8 to 17 V
DIMMING
Manual, full to 1/4
WEIGHT
700 g/1.5 lbs
MOUNT
yoke, shoe, handle





TWINLITE


This modular fluorescent system is light weight and controllable. It is used in applications with very low ceilings, teleconferencing rooms, car interior shooting, duplication bench, portable kit case… The 2x1 lamps, 100 W, are equivalent to 900W Halogen.
  TWINLITE 2 X 50
Power in Candelas 2 x 1 500
Angle lit 50°
"Daylight" CRI 90 series lamps yes
3200°K CRI 90 series lamps yes
Wattage 100W
AC Mains 50/60 HZ 120 V 0.9A
230 V 0.5A
Ballast HF 56 kHz yes
Dimming (0-3 to 100%) Phase yes
0/+10V -
DMX-512 -
manual yes
Housing Aluminium extrusions and epoxy coated aluminium alloy sheet
Adjustable reflecting flaps 2
removable corners 2
Mounting female Ø 16 mm / 5/8"
Yoke manual -
pole op. yoke -
Weight depending on model Reflector : 1.3 kg/2.9lbs
Power pack 1.8kg/4lbs
Accessories 40° grid, prismatic diffuser, filter holder, joining bar
