LONG DISTANCE LIGHT

1000 LUX at 5m (POWERFLUX 2) for 340W, up to 20 times more efficient than Tungsten softlights.
Gives the effect of a Fresnel fitted with a light diffuser. Up to 6 times more efficient (POWERFLUX 2 equivalent light output to a 2KW Fresnel).
As a cyclorama light, the POWERFLUX reduces electrical consumption by 80%.
Allows DMX control of the entire studio, by replacing conventional power hungry key lights, soft lights and cyclorama lights.
Low electrical consumption, with little heat generation.
Long bulb life.

The POWERFLUX is the only fluorescent fixture able to effectively light at distances between 3 to 7 meters (10 to 25 ft). Its outstanding efficiency enables fluorescence to be used in production studios with high grid systems, either as a main light, fill light or cyclorama light.

The POWERFLUX is used as a main or fill light for applications that require it to be at 3 to 7 meters (10 to 25 ft). It best compares to a traditional 5K tungsten softlight (POWERFLUX 1) or 10K (POWERFLUX 2).

As a key light, the POWERFLUX 2 is more versatile than a 2KW Fresnel spot fitted with a light diffuser, allowing precise dimming with no change in color temperature and no heat on the subject.

As a cyclorama light, it can be spaced from the wall at 1/2 of the height for even light distribution, with significant benefits in energy reduction and dimming (special reflector accessory, soon available).

The POWERFLUX 2 is effectively two POWERFLUX 1 units side by side. In DMX mode, both cells can be controlled on the same channel or separately (consecutive channel).

Recommendation for POWERFLUX vs. distance
POWERFLUX 1 distance to subject 3m (1500LUX) or 5m (500 LUX)
distance to subject 10ft (120 FC) or 15ft (50 FC)
POWERFLUX 2 distance to subject 5m (1000 LUX) or 7m (510 LUX)
distance to subject 15ft (100FC) or 25 ft (40 FC)



POWERFLUX 1

POWERFLUX 2



  POWERFLUX 1 POWERFLUX 2
POWER 170 W 340 W
NUMBER OF LAMPS 4 8
COLOR TEMPERATURE Ra 80 series lamps type 3200K, 4200K or 5000K Ra 80 series lamps type 3200K, 4200K or 5000K
AC MAINS 50/60 Hz 120V 1.5 A max. 3 A max.
230V 1 A max. 2 A max.
HF BALLAST 56 kHz 56 kHz
DIMMING (0-3 to 100%) DMX-512, manual DMX-512 (1 or 2 chanels), manual
HOUSING Steel, cataphoresis protected Steel, cataphoresis protected
LIGHT OUTPUT   12 500 Candelas Hor. Angle Vert. Angle   25 000 Candelas Hor. Angle Vert. Angle
3 m/ 5m 1400 lux / 500 lux 35° 35° 5 m / 7 m 1000 lux / 510 lux 40° 35 °
10 ft/15 ft 120 FC / 50 FC 35° 35° 15 ft/25 ft 100 FC / 40 FC 40° 35 °
MOUNTING male 28 mm / 11/8" male 28 mm / 11/8"
YOKE manual, Pole-Op. (option), floor mount (option) manual, Pole-Op. (option), floor mount (option)
WEIGHT 9.75 kg (21.5 lbs) 17.50 kg (38.5 lbs)
ACCESSORIES Grids, Pole Operated, hanging systems… Grids, Pole Operated, hanging systems…
